SpeedyBee 5.8GHz Goggles Receiver Module

Description

Experience a new level of FPV flying with the SpeedyBee 5.8GHz Goggles Receiver Module. This advanced receiver is designed to deliver superior video clarity and stability, even in challenging signal environments. Featuring dual internal 5.8GHz receivers and a dedicated chip for real-time signal analysis and fusion, it provides a more stable picture than traditional diversity receivers. The module fits into a standard receiver bay, making it compatible with a wide range of FPV goggles, including Fat Shark Dominator, Orqa, and HDZero series. It also supports DJI V1 and V2 goggles with an optional adapter. With a 128×64 pixel OLED display and a 5-way button, you can easily navigate menus and access features like frequency lock, band scanning, and a “Find Drone” function that assists in locating a lost drone by displaying signal strength and emitting beeping sounds. The built-in RSSI OSD provides a real-time signal strength display on your goggles, ensuring safe operation.

Specifications

• Operating Voltage:5V
• Operating Current:450mA@5V
• Supported FPV Goggles:
  • Fat Shark Dominator series (V1, V2, V3, SE, HD1, HD2, HD3, HDO, HDO2)
  • Orqa (requires 3D-printed housing)
  • HDZero (supports analog conversion module)
  • DJI (V1, V2 with separate adapter board)
• Working Frequency:A, B, E, F, R, L bands with 48 channels (5.3GHz-5.9GHz)
• Dimensions:51x34x17.8mm
• Weight:32.8g
