RunCam Link WASP Kit

Description

RunCam Link WASP Kit

Introducing the Runcam Link Wasp HD Camera and VTX Kit – an advanced video transmission solution developed by Runcam and fully authorized by DJI. This kit is tailor-made for FPV drones, delivering exceptional performance with a 5.8GHz digital video signal and 720p 120fps image transmission.

Designed to seamlessly integrate with DJI FPV Goggles, the Runcam Link Wasp HD Camera and VTX Kit ensures a crystal-clear, high-definition visual experience with a transmission range of up to 4km. Experience the freedom of connecting up to eight drones simultaneously through the Link system, providing each operator with an exclusive channel. This not only minimizes cross-interference but also enhances the overall racing experience.

What sets this kit apart is its wireless compatibility with the DJI FPV Remote Controller and DJI FPV Goggles, eliminating the need for additional receivers. Enjoy a hassle-free setup that brings cutting-edge technology to your fingertips. Elevate your FPV drone experience with the Runcam Link Wasp HD Camera and VTX Kit.

Features

• Beautiful 1280×720@120fps FPV feed
• Excellent low-light performance
• Microform factor for better frame compatibility

Specifications

Phoenix Wasp HD Camera

• Image Sensor: 1/3”
• Resolution: 720p@120fps(4:3)
• LENS: FOV D:155° H:125° V:96°
• Shutter: Rolling Shutter
• Coaxial Cable: 120 mm
• Dimensions: L19mmxW19mmxH19mm
• Net Weight: 7.5g

Link Air Unit

• Input Voltage: 7.4-26.4V@ 4-9W
• Operating Frequency: 5.725-5.850 GHz
• Transmitter Power: (EIRP) FCC/SRRC: <30 dBm; CE: <14 dBm
• Min. Latency (end-to-end): 1280 x 720 60fps: 32 ms
• Max. Transmission Distance: FCC/SRRC: 4 km; CE: 0.7 km;
• I/O Interface: Type-C, IPEX, 3-in-1 port,
• Supported Flight Control System: BetaFlight
• Operating Temperature Range: 0° to 40° C (32° to 104° F)
• Coaxial Cable: 120 mm
• Dimensions: 29x29x13mm
• Weight(camera included): 27g

Includes

• 1x RunCam Link Wasp HD Micro Kit for DJI
• 1x RunCam Link Air Unit
• 1x RunCam Link U.FL Antenna
• 1x 6 Pin Cable – JST-SH1.0
• 1x 12cm Cable
