Walksnail Avatar Repeater

Description

Unlock the full potential of your FPV system with the Walksnail Avatar Repeater, the first HD digital video transmission repeater designed to boost signal strength, expand range, and reduce interference for smoother and more reliable flights. Featuring dual-band 5.2GHz and 5.8GHz high-power transmission, it is equipped with high-gain LHCP directional antennas (7dBi avg.) to amplify signals in challenging environments such as long-range flying, film production, or remote landscape photography.

The repeater supports 1080p/100fps, 1080p/60fps, 720p/100fps, and 720p/60fps transmission resolutions via the Avatar HD system, maintaining sharp, low-latency visuals over extended distances. Its built-in hardware filter minimizes adjacent channel interference for stable video feeds. Simple 4-step pairing makes setup quick and reliable.

Compatible with Walksnail Goggles X, Avatar VRX, and all current Walksnail VTX systems, this repeater is a must-have tool for pilots looking to increase performance in both recreational and professional FPV operations. Power input is flexible with support for 9V–26V, allowing for seamless integration with drone ground stations or mobile setups.

Specifications:

• System:Avatar HD System

• Power Input:9V–26V

• Dimensions:119.5 × 72 × 18.6 mm

• Weight:145.9g (antenna not included)

• I/O Interface:USB, 4-Pin 1.0mm Port

• Transmission Resolutions:

  • 1080p @ 100fps, 60fps

  • 720p @ 100fps, 60fps

• Communication Frequencies:

  • 5.15–5.30GHz (5.2G)

  • 5.50–5.85GHz (5.8G)

• Transmitter Power (EIRP):

  • FCC: <30dBm

  • CE: <14dBm

  • SRRC: <20dBm

  • MIC: <25dBm

• 5.2G Antenna:

  • Gain: 7dBi (avg)

  • Polarization: LHCP

• 5.8G Antenna:

  • Gain: 7dBi (avg)

  • Polarization: LHCP
