Castle Creations CC BEC Pro Switching Regulator 20A Peak

Description

Description:
Upgrade your RC experience with the Castle Creations CC BEC Pro Switching Regulator, a must-have for high-powered applications. This compact Battery Eliminator Circuit (BEC) draws high voltage from motor batteries and optimally converts it to a receiver-friendly level, eliminating the need for a separate battery pack. Perfect for setups with high power demands, this regulator ensures smooth performance and efficiency for your receiver and servos.

Features:

• Compact Design:Measuring only 1.69″ (43mm) in length, 1.3″ (33mm) in width, and 0.94″ (24mm) in height, with a lightweight 1 oz (29g) body.
• High Current Capability:Supports up to 20 amps peak current, with varying continuous currents based on input voltage (15 amps at 16 volts input to 8 amps at 48 volts input).
• Adjustable Output Voltage:Flexible output ranging from 4.8V to 12.5V, catering to diverse servo and receiver requirements.
• Wide Voltage Range:Suitable for cars (up to 6s, 25V), airplanes (up to 10s, 40V), and helicopters (up to 12s, 50V) with the brake disabled.
• Enhanced Efficiency:Designed for applications with multiple servos or those exceeding 3S motor packs, where typical ESCs with linear BECs fall short.

Why You Should Buy:
Invest in reliability and performance with the Castle Creations CC BEC Pro Switching Regulator. Its high efficiency and flexible output make it ideal for serious RC hobbyists and professionals seeking dependable power solutions for demanding applications. Ensure optimal performance and safety for your equipment with this advanced BEC.

Important Note:
The CC BEC Pro should never be used in series or parallel with another BEC or backup receiver pack connected to the RX/Servo side of the circuit. Always adhere to these guidelines to ensure safe and effective operation.

• Width: 1.3″ (33mm)
• Height: 0.94″ (24mm)
• Weight: 1 oz* (29g*)
• Max Amps:20 amps peak**                    Max continuous current**                    16 volts input = 15 amps                    24 volts input = 13 amps                    32 volts input = 11 amps                    40 volts input = 9 amps                    48 volts input = 8 amps
• Max Volts:Cars: 6s (25v)                     Airplanes: 10s (40v)                     Helicopters (with brake disabled): 12s (50v)
• Adjustable Output Voltage: 4.8V to 12.5V
