Walksnail VTX Antenna (2pcs)

Description

Upgrade your FPV system with the Walksnail VTX Antenna (2pcs)—a pair of high-performance omnidirectional CP antennas engineered for both HD and analog video transmission. Featuring a new LDS process, these antennas provide exceptional efficiency and high manufacturing consistency, ensuring strong and stable signal performance.

Designed with a rugged polycarbonate shell, they offer superior durability, ideal for FPV drones, goggles, and ground stations. The compact short-tail designmakes them a perfect fit for goggles and tight installation spaces, while the wide bandwidth range (5600–6000MHz)ensures optimal compatibility across digital and analog systems.

These LHCP antennas boast excellent radiation efficiency (≥97%), a strong 2dBi gain, and low VSWR (≤1.4), resulting in minimal signal loss and reduced interference. Whether you’re flying freestyle, racing, or capturing cinematic FPV footage, these antennas will elevate your transmission clarity and reliability.

Specifications:

• Type:Omnidirectional Circular Polarized (CP) Antenna

• Polarization:LHCP

• Bandwidth:5600MHz–6000MHz

• Gain:2dBi

• Radiation Efficiency:≥97%

• VSWR:≤1.4

• Cross-Polar Rejection:-15 to -30dB

• Connector:IPEX1

• Dimensions:H24.8mm × R15.3mm

• Weight:4.2g per antenna

• Quantity:2 antennas per pack
